You have invested significant capital in your Distillery Equipment. But the day it is installed is just the beginning.
A still is a living ecosystem of heat, pressure, and chemical reactions. Over time, copper oxidizes, gaskets compress, and sensors drift. If neglected, your equipment won't just look bad—it will start to produce spirits with off-flavors (like sulfur) or, worse, become a safety hazard.
To choose the best maintenance routine, you need a proactive mindset. In this guide, we outline the essential daily, weekly, and monthly tasks that keep your distillery running safely and efficiently for decades.
Maintenance starts the moment a run finishes. The goal is to leave the equipment neutral and sanitary for the next batch.
Most modern Cassman Distillery Systems come equipped with spray balls.
The Rinse: Immediately after emptying the still, rinse with hot water (80°C) to remove grain solids and yeast.
The Caustic Cycle: Use a caustic solution to break down organic proteins inside the pot and column.
The Safety Check: While cleaning, visually inspect the Pressure Relief Valve (PRV). Ensure it is not clogged with grain or foam. This is your primary safety line against over-pressure.
Copper removes sulfur from your spirit, but it sacrifices itself in the process.
The Issue: After a run, the inside of your copper helmet will look black or dull. This is copper sulfide.
The Fix: If the copper is coated in "gunk," it cannot react with the next batch. A quick acid rinse (Citric Acid) helps expose fresh copper for the next run.
Once a week or month, you need to look closer at the wear-and-tear components.
Tri-clamp gaskets (EPDM, Silicone, or PTFE) are subjected to extreme heat cycles.
What to look for: Cracks, brittleness, or flattening.
Action: Replace any gasket that looks worn. A $5 gasket failure can ruin a $5,000 batch of whiskey if it causes a leak during distillation.
Electric Elements: Pull them out periodically to check for "scorching" or scale buildup. Scale acts as an insulator, causing the element to overheat and burn out.
Steam Traps: If you use steam, check your traps. A failed trap can cause water hammer, which can crack your stainless steel jacket.
Check the mechanical seal on your agitator motor. If you see oil dripping into the pot or vapor escaping from the shaft, the seal needs immediate replacement.
Even with the best maintenance, issues arise. Here is how to handle them.
Symptom: Liquid wash rises up the column and contaminates the condenser.
Cause: Running the heat too high or overfilling the pot.
Fix: Reduce the fill level (max 80% capacity) and use a defoaming agent. Check your heating ramp rates.
Symptom: Vapor escaping from column sections.
Cause: Loose clamps or thermal expansion.
Fix: Tighten clamps after the still has heated up. Metal expands when hot, so a clamp that was tight when cold might become loose (or vice versa depending on the bolt type).
One of the biggest challenges in maintenance is getting spare parts.
If you buy from a local reseller, you are often waiting for them to order a part from overseas, adding a markup, and shipping it to you.
Direct Access: When you buy Factory Direct from Cassman, you have a direct line to the warehouse. We stock standard heating elements, gaskets, and manway seals.
Technical Support: Need to know the torque spec for a bolt? You can ask our engineers directly via video call, ensuring you don't damage your equipment during maintenance.
Q: How do I keep my copper still looking shiny on the outside?
A: The outside is just for aesthetics. You can use a commercial copper polish and a soft cloth. Never use abrasive pads (like steel wool) on the outside, as it will scratch the mirror finish.
Q: How often should I replace my gaskets?
A: We recommend a full replacement of all high-heat gaskets (pot and column) once a year. Keep a "Spare Parts Kit" on the shelf so you are never down for a day waiting for a seal.
Q: Can I use chlorine bleach to clean my stainless steel tanks?
A:NEVER. Chlorine causes pitting corrosion in stainless steel, which can lead to pinhole leaks. Always use non-chlorinated alkaline cleaners or caustic soda.
Great spirits are consistent. And consistency is impossible with dirty or malfunctioning equipment.
By establishing a rigorous maintenance schedule, you not only extend the life of your Distillery Equipment but also ensure that every bottle you produce meets your high standards.
