CM 2-2 Canning System
Cassman
For the ambitious craft brewery, moving from manual or mobile canning to an in-house automated solution is the most critical step toward growth. The CM 2-2 Canning System is engineered to be that perfect step. It delivers the speed, quality, and flexibility you need to meet demand, packaged in a compact and operator-friendly design.
Your beverage's quality is paramount. Our system is designed from the ground up to protect the flavor and stability you worked so hard to create.
High-Speed Throughput: With a reliable output of 800-1000 cans per hour, this 2-station system allows you to meet retailer demands, expand your distribution footprint, and significantly increase your revenue potential.
Ultra-Low Dissolved Oxygen (DO): Achieve industry-leading performance with DO levels of ≤20ppb. Our pre-fill CO₂ purge function ensures your product is protected from flavor-destroying oxygen, guaranteeing longer shelf life and a tap-fresh taste for your customers.
Effortless Flexibility: Don't be locked into one can size. Our system can be configured for nearly all standard, sleek, or slim cans. Changeovers are a snap, requiring only simple tools and less than 30 minutes to complete—perfect for seasonal releases and diverse product lines.
Precision & Durability: Equipped with a high-performance Cemented Carbide seamer and powered by a reliable Panasonic Motor, the CM 2-2 delivers consistent, leak-proof seams you can trust, minimizing product loss and maximizing operational uptime.
Intuitive Operation: A modern F110 Capacitive Touch Screen provides a simple, user-friendly interface for setting and adjusting all timing parameters, including can rinsing and pre-fill purging.
Maximize your efficiency by automating your workflow. The Rotary Infeed Table provides a continuous, hands-free supply of empty cans to your canning system, allowing your operator to focus on quality control and pack-off.
Speed: Adjustable to perfectly match the canning line's pace.
Construction: Built with the same durable AISI304 Stainless Steel and POM materials.
Power: Simple plug-and-play single-phase power (500W).
CM 2-2 Canning System
| Parameter | Specification |
|---|---|
| Capacity | 800-1000 Cans Per Hour (2-Station) |
| Dissolved Oxygen | ≤20ppb |
| Dimensions (L×W×H) | 1.20m × 0.80m × 1.80m |
| Weight | 200kg |
| Power Supply | Single Phase 110V-240V, 50/60Hz |
| Power Consumption | 900W |
| Main Materials | AISI 304 Stainless Steel, Aluminum Alloy, POM |
| Can Size Changeover | < 30 minutes |
| Lead Time | 30-35 Days |
Utility Requirements
| Utility | Specification |
|---|---|
| Beer Source | Temp: -1 to 0°C; Carbonation: 2.4-2.7 vols; Pressure: 22 psi (0.15MPa) |
| CO₂ Supply | 58-65 psi (0.4-0.45MPa) via 10mm OD fitting |
| Air Supply | 87-102 psi (0.6-0.7MPa) via 10mm OD fitting |
Stop letting packaging be your bottleneck. The CM 2-2 Canning System offers the speed, quality, and reliability you need to grow your brand.
Contact us today for a personalized quote and discover how affordable and easy in-house automated canning can be!
